XYO Financial SDK for C++

The official C++ SDK for XYO Financial.
Seamlessly enrich raw financial transactions into clean merchant profiles, intelligent business categorizations, high-res logos, and geolocated address metadata using AI-powered enrichment pipelines.

📖 Summary

The XYO Financial SDK for C++ provides an institutional-grade, modern C++17 client library for integrating XYO's AI-driven transaction enrichment engine into high-performance financial systems, payment gateways, low-latency banking microservices, and core banking ledgers.

Engineered for Tier-1 banks, payment service providers (PSPs), quantitative hedge funds, and fintech platforms, this SDK transforms raw, cryptic merchant statement strings (e.g. AMZN MKTP UK*1M23456, SQ *COSTA GREENWICH SE10, UBER *TRIP HELP.UBER.COM) into verified, structured merchant intelligence complete with official merchant identities, industry classification taxonomies, brand logos, geocoded coordinates, and physical street addresses.

Maintained by Syniol Limited as the official C++ distribution for XYO.Financial.

🏗 Architectural Principles

Modern PIMPL Architecture:
- Public Header (xyo/client.hpp): Clean, idiomatic public API exposing strictly standard C++17 types (std::string, std::optional, std::vector, std::unique_ptr).
- Zero Leaky Abstractions: Third-party headers (<cpr/*>, <nlohmann/*>, <zlib.h>) are completely encapsulated in src/client.cpp. Consuming applications never pull third-party headers into their translation units.
Thread-Safe & Re-Entrant: xyo::Client instances are thread-safe and can be safely shared across concurrent worker pools, async task executors, and multithreaded backend pipelines.
Memory Safety & Move Semantics: Fully RAII-compliant with move-only configuration objects and zero manual pointer management, eliminating memory leaks and phantom key allocations.
In-Memory Archive Streaming: Direct in-memory .tar.gz decompression (via zlib) and custom zero-copy POSIX ustar/GNU tar archive parsing for instantaneous bulk result ingestion without disk I/O.
Structured Error Hierarchy: Tagged error categories (validation, transport, http, parsing) paired with numeric HTTP status codes and transport error diagnostics.

⚙️ System Requirements

C++ Standard: C++17 or newer.
Compilers:
- GCC 9.0+ (Linux / WSL)
- Clang 10.0+ / Apple Clang 12.0+ (macOS / Linux)
- Microsoft Visual Studio (MSVC) 2019+ / 2022+ (Windows)
Build System: CMake 3.16 or newer.
Dependencies:
- cpr (1.10+)
- nlohmann_json (3.11+)
- OpenSSL (1.1+ or 3.0+)
- ZLIB (1.2.8+)
Network: Outbound HTTPS connectivity to api.xyo.financial over port 443 (TLS 1.2+ mandatory).
Authentication: A valid API Bearer token obtained from the XYO Financial Dashboard.

📦 Installation & Integration

Option 1: Conan 2 (Recommended)

Add xyo-sdk to your conanfile.txt:

[requires]
xyo-sdk/2.1.0

[generators]
CMakeDeps
CMakeToolchain

[layout]
cmake_layout

Install and build your project:

conan install . --build=missing
cmake --preset conan-release
cmake --build --preset conan-release

Option 2: vcpkg

Install the package via vcpkg:

vcpkg install xyo-sdk

Configure your CMake project with the vcpkg toolchain:

cmake -B build -S . -DCMAKE_TOOLCHAIN_FILE=${VCPKG_ROOT}/scripts/buildsystems/vcpkg.cmake
cmake --build build

Option 3: CMake `find_package` (Installed Binaries)

When linking against an installed copy of the SDK:

cmake_minimum_required(VERSION 3.16)
project(FinancialApp LANGUAGES CXX)

set(CMAKE_CXX_STANDARD 17)
set(CMAKE_CXX_STANDARD_REQUIRED ON)

# Discover SDK target
find_package(XYOSDK CONFIG REQUIRED)

add_executable(financial_app main.cpp)
target_link_libraries(financial_app PRIVATE XYO::SDK)

Option 4: CMake `FetchContent` (Direct from Source)

Integrate the SDK directly into your CMake project without pre-installing dependencies:

include(FetchContent)

FetchContent_Declare(
  xyo_sdk
  GIT_REPOSITORY https://github.com/xyo-financial/sdk-cpp.git
  GIT_TAG        v2.1.0
)
FetchContent_MakeAvailable(xyo_sdk)

add_executable(financial_app main.cpp)
target_link_libraries(financial_app PRIVATE XYO::SDK)

🚀 Quickstart Guide

#include <xyo/client.hpp>
#include <iostream>

int main() {
  try {
    // 1. Initialize client configuration
    xyo::ClientConfig config("YOUR_XYO_API_KEY");
    config.request_timeout_ms = 10000; // 10s request timeout

    xyo::Client client(std::move(config));

    // 2. Enrich a single transaction
    xyo::EnrichmentRequest request{
        /* content      = */ "COSTA PICKUP GREENWICH",
        /* country_code = */ "GB"
    };

    xyo::EnrichmentResponse response = client.enrichTransaction(request);

    std::cout << "--- Transaction Enrichment Result ---\n";
    std::cout << "Merchant:    " << response.merchant << "\n";
    std::cout << "Description: " << response.description << "\n";
    std::cout << "Categories:  ";
    for (const auto& cat : response.categories) {
      std::cout << "[" << cat << "] ";
    }
    std::cout << "\n";

    if (response.location) {
      std::cout << "Location:    " << *response.location << "\n";
    }
    if (response.address) {
      std::cout << "Address:     " << *response.address << "\n";
    }

  } catch (const xyo::Error& e) {
    std::cerr << "XYO Error (" << static_cast<int>(e.category())
              << "): " << e.what()
              << " [HTTP " << e.http_status_code() << "]\n";
    return 1;
  }

  return 0;
}

📚 Comprehensive Usage Workflows

1. Single Transaction Enrichment (`enrichTransaction`)

Synchronously enrich individual transactions in real-time. Ideal for payment authorization hooks, mobile banking applications, and personal finance ledgers:

#include <xyo/client.hpp>
#include <iostream>

void enrichSingle(const xyo::Client& client) {
  xyo::EnrichmentRequest req{
      "AMZN MKTP US*2819873", // Raw bank statement narrative (max 128 chars)
      "US"                    // ISO 3166-1 alpha-2 country code
  };

  xyo::EnrichmentResponse res = client.enrichTransaction(req);

  std::cout << "Merchant:    " << res.merchant << "\n";
  std::cout << "Description: " << res.description << "\n";
  std::cout << "Logo (B64):  " << (res.logo.empty() ? "N/A" : "Available") << "\n";

  if (res.location.has_value()) {
    std::cout << "Location:    " << res.location.value() << "\n";
  }
  if (res.address.has_value()) {
    std::cout << "Address:     " << res.address.value() << "\n";
  }
}

Response Model Fields:

Field	Type	Description
`merchant`	`std::string`	Official, normalized merchant brand name (e.g. `"Amazon"`).
`description`	`std::string`	Detailed business description and merchant operational profile.
`categories`	`std::vector<std::string>`	Industry classification taxonomy categories.
`logo`	`std::string`	Base64-encoded brand logo (PNG/JPEG format).
`location`	`std::optional<std::string>`	Geocoded city or regional market (if detected).
`address`	`std::optional<std::string>`	Verified street address of the transaction point (if detected).

2. Bulk Transaction Submission (`enrichTransactions`)

Submit high-volume transaction batches asynchronously for ETL processing, nightly batch reconciliation, and core banking statement generation:

#include <xyo/client.hpp>
#include <iostream>
#include <vector>

xyo::BulkEnrichmentResponse submitBatch(const xyo::Client& client) {
  std::vector<xyo::EnrichmentRequest> batch = {
      {"UBER *TRIP HELP.UBER.COM", "US"},
      {"NETFLIX.COM PAYMENT", "GB"},
      {"AMZN MKTP US*2819873", "US"},
      {"TESCO STORES 2891", "GB"}
  };

  // Submit batch job (returns job identifier and download URL)
  xyo::BulkEnrichmentResponse bulk = client.enrichTransactions(batch);

  std::cout << "Bulk Job ID:     " << bulk.id << "\n";
  std::cout << "Download Link:   " << bulk.link << "\n";

  return bulk;
}

3. Bulk Job Status Polling (`getEnrichmentStatus`)

Poll the processing status of an asynchronous bulk enrichment job until the results archive is ready for ingestion:

#include <xyo/client.hpp>
#include <chrono>
#include <iostream>
#include <thread>

void pollJob(const xyo::Client& client, const std::string& jobId) {
  std::cout << "Polling status for job: " << jobId << "...\n";

  while (true) {
    xyo::EnrichmentStatus status = client.getEnrichmentStatus(jobId);
    std::cout << "Status: " << xyo::to_string(status) << "\n";

    if (status == xyo::EnrichmentStatus::ready) {
      std::cout << "Job is READY! Proceeding to download archive.\n";
      break;
    } else if (status == xyo::EnrichmentStatus::failed) {
      std::cerr << "Job FAILED during processing on server.\n";
      break;
    }

    // Wait before next polling iteration
    std::this_thread::sleep_for(std::chrono::seconds(2));
  }
}

4. Direct Bulk Results Download & Decompression (`downloadEnrichmentCollection`)

Once a bulk enrichment job reaches ready status, download and unpack the compressed archive directly into a vector of domain models without touching disk:

#include <xyo/client.hpp>
#include <iostream>
#include <vector>

void processBulkResults(const xyo::Client& client, const std::string& downloadUrl) {
  // downloadUrl is the `link` URL from BulkEnrichmentResponse
  std::vector<xyo::EnrichmentResponse> records =
      client.downloadEnrichmentCollection(downloadUrl);

  std::cout << "Successfully downloaded and unpacked " << records.size() << " enriched transactions:\n";

  for (const auto& record : records) {
    std::cout << "----------------------------------------\n";
    std::cout << "Merchant:    " << record.merchant << "\n";
    std::cout << "Description: " << record.description << "\n";
    std::cout << "Categories:  ";
    for (const auto& cat : record.categories) {
      std::cout << "[" << cat << "] ";
    }
    std::cout << "\n";
  }
}

🚀 Framework & Architecture Integration

1. Modern C++17 Microservice Integration (Crow / Drogon)

Integrate xyo::Client into modern, asynchronous C++ web microservices to enrich incoming payment streams at high concurrency. The SDK is thread-safe and re-entrant, allowing a single client instance to be shared across worker thread pools.

Crow Microservice Recipe

#include <xyo/client.hpp>
#include <crow.h>
#include <cstdlib>

int main() {
    crow::SimpleApp app;

    // 1. Initialize thread-safe XYO client with strict ledger SLA budget
    const char* apiKey = std::getenv("XYO_API_KEY");
    xyo::ClientConfig config(apiKey ? apiKey : "YOUR_API_KEY");
    config.request_timeout_ms = 500; // Strict 500ms ledger budget
    xyo::Client xyoClient(std::move(config));

    // 2. High-performance REST enrichment endpoint
    CROW_ROUTE(app, "/api/enrich").methods("POST"_method)
    ([&xyoClient](const crow::request& req) {
        auto payload = crow::json::load(req.body);
        if (!payload) {
            return crow::response(400, "{\"error\": \"Malformed JSON payload\"}");
        }

        try {
            xyo::EnrichmentRequest request{
                payload["content"].s(),
                payload["countryCode"].s()
            };
            auto response = xyoClient.enrichTransaction(request);

            crow::json::wvalue res;
            res["merchant"]    = response.merchant;
            res["description"] = response.description;
            res["categories"]  = response.categories;
            if (response.location.has_value()) res["location"] = response.location.value();
            if (response.address.has_value())  res["address"]  = response.address.value();

            return crow::response{200, res};
        } catch (const xyo::Error& err) {
            crow::json::wvalue errRes;
            errRes["error"] = err.what();
            errRes["category"] = static_cast<int>(err.category());
            return crow::response{
                err.http_status_code() ? static_cast<int>(err.http_status_code()) : 500,
                errRes
            };
        }
    });

    // Run multithreaded server with worker threads
    app.port(8080).multithreaded().run();
}

Drogon Asynchronous Controller Recipe

#include <xyo/client.hpp>
#include <drogon/drogon.h>
#include <cstdlib>
#include <memory>

class EnrichmentController : public drogon::HttpController<EnrichmentController> {
public:
    METHOD_LIST_BEGIN
    ADD_METHOD_TO(EnrichmentController::enrich, "/api/enrich", drogon::Post);
    METHOD_LIST_END

    EnrichmentController() {
        const char* apiKey = std::getenv("XYO_API_KEY");
        xyo::ClientConfig config(apiKey ? apiKey : "YOUR_API_KEY");
        config.request_timeout_ms = 500; // Strict 500ms ledger budget
        client_ = std::make_unique<xyo::Client>(std::move(config));
    }

    void enrich(const drogon::HttpRequestPtr& req,
                std::function<void(const drogon::HttpResponsePtr&)>&& callback) {
        auto json = req->getJsonObject();
        if (!json) {
            auto resp = drogon::HttpResponse::newHttpResponse();
            resp->setStatusCode(drogon::k400BadRequest);
            resp->setBody("{\"error\": \"Missing or invalid JSON payload\"}");
            callback(resp);
            return;
        }

        try {
            xyo::EnrichmentRequest request{
                (*json)["content"].asString(),
                (*json)["countryCode"].asString()
            };
            auto response = client_->enrichTransaction(request);

            Json::Value res;
            res["merchant"]    = response.merchant;
            res["description"] = response.description;
            for (const auto& cat : response.categories) {
                res["categories"].append(cat);
            }
            if (response.location) res["location"] = *response.location;
            if (response.address)  res["address"]  = *response.address;

            auto resp = drogon::HttpResponse::newHttpJsonResponse(res);
            callback(resp);
        } catch (const xyo::Error& err) {
            auto resp = drogon::HttpResponse::newHttpResponse();
            resp->setStatusCode(err.http_status_code()
                ? static_cast<drogon::HttpStatusCode>(err.http_status_code())
                : drogon::k500InternalServerError);
            resp->setBody(err.what());
            callback(resp);
        }
    }

private:
    std::unique_ptr<xyo::Client> client_;
};

2. High-Frequency Trading & Low-Latency Banking Ledgers

For institutional core ledgers, settlement engines, and high-frequency transaction processing pipelines, C++ provides deterministic execution guarantees that are impossible with managed runtimes:

Zero Garbage Collection Pause Jitter: Managed runtimes (Java, Node.js, Go, .NET) experience unpredictable stop-the-world GC pauses that degrade tail latency (p99/p99.9). The C++ SDK utilizes deterministic RAII memory management, achieving zero Garbage Collection pause jitter (deterministic sub-millisecond p99 execution) for critical financial rails and real-time fraud mitigation gates.
PIMPL Compilation Speed & Monorepo Isolation: The SDK's Pointer-to-Implementation (PIMPL) architecture encapsulates all transport and third-party dependencies (cpprestsdk, Boost, OpenSSL, zlib) strictly within src/client.cpp. Header inclusion is instantaneous (<xyo/client.hpp> only imports standard library headers), eliminating translation-unit header bloat and drastically accelerating compile and link times in massive enterprise monorepos.
Lock-Free Concurrency & Zero-Copy Streaming: Public client methods are re-entrant and thread-safe without requiring application-level mutex locking. Bulk transaction collections are decompressed directly in memory through zero-copy streaming, bypassing disk I/O bottlenecks.

🛡 Structured Error Handling (`xyo::Error`)

All SDK exceptions inherit from std::runtime_error and provide strongly typed error categorization and diagnostic codes:

#include <xyo/client.hpp>
#include <iostream>

void safeExecute(const xyo::Client& client) {
  try {
    xyo::EnrichmentRequest req{"", "GB"}; // Empty string triggers validation error
    auto res = client.enrichTransaction(req);
  } catch (const xyo::Error& err) {
    std::cerr << "[Error Caught] " << err.what() << "\n";

    switch (err.category()) {
      case xyo::ErrorCategory::validation:
        std::cerr << "Classification: Client validation error (e.g. empty API key or payload).\n";
        break;

      case xyo::ErrorCategory::transport:
        std::cerr << "Classification: Network/transport layer failure (code: "
                  << err.transport_code() << ").\n";
        break;

      case xyo::ErrorCategory::http:
        std::cerr << "Classification: Server HTTP error (Status: "
                  << err.http_status_code() << ").\n";
        if (err.http_status_code() == 401) {
          std::cerr << "Action: Verify your API key at https://xyo.financial/dashboard.\n";
        } else if (err.http_status_code() == 429) {
          std::cerr << "Action: Rate limit reached. Backoff and retry.\n";
        }
        break;

      case xyo::ErrorCategory::parsing:
        std::cerr << "Classification: Response parsing / deserialization failure.\n";
        break;
    }
  }
}

HTTP Status Code Reference

HTTP Code	Classification	Root Cause & Mitigation
`400`	Bad Request	Malformed JSON payload or invalid ISO 3166-1 country code.
`401`	Unauthorized	Bearer token is missing, expired, or invalid.
`403`	Forbidden	Insufficient plan permissions or account quota exhausted.
`404`	Not Found	Bulk work-ID not located or expired.
`422`	Unprocessable Entity	Content string cannot be parsed into a recognizable merchant format.
`429`	Rate Limited	API request volume quota exceeded. Apply backoff and retry.
`500` / `502` / `503`	Server Error	Upstream infrastructure degradation. Reroute to secondary queue.

⚙️ Advanced Configuration Reference

The xyo::ClientConfig struct governs connection, authentication, and timeout parameters:

Field	Type	Default	Description
`api_key`	`std::string`	(Required)	Secret API Bearer token from the XYO dashboard
`base_url`	`std::string`	`"https://api.xyo.financial"`	API gateway base endpoint URL
`connect_timeout_ms`	`long`	`5000` (5s)	Reserved for future transport backends. Currently governed by `request_timeout_ms`.
`request_timeout_ms`	`long`	`30000` (30s)	End-to-end HTTP request timeout in milliseconds
`max_collection_size`	`std::size_t`	`1000`	Maximum item limit per batch request

🔒 Security & Compliance

Data Minimisation: Transmit only transaction string narratives and ISO country codes. Never transmit Primary Account Numbers (PANs), CVVs, passwords, or Personally Identifiable Information (PII).
Transport Security: Outbound communication strictly enforces TLS 1.2+ HTTPS encryption.
Memory Hardening: ClientConfig securely manages API key memory lifecycles using RAII move semantics.

🧪 Build from Source & Run Tests

# 1. Configure build
cmake -S . -B build -DCMAKE_BUILD_TYPE=Release -DXYO_BUILD_TESTS=ON

# 2. Compile SDK library and test suite
cmake --build build --parallel

# 3. Execute unit and integration tests
ctest --test-dir build --output-on-failure

📞 Support

Developer Dashboard: https://xyo.financial/dashboard
Technical Support: support@syniol.com
Maintainer: Syniol Limited

📄 License

This project is licensed under the Apache License, Version 2.0 - see the LICENSE file for details.

Name		Name	Last commit message	Last commit date
.github/workflows		.github/workflows
cmake		cmake
docs		docs
example		example
include/xyo		include/xyo
openapi		openapi
packaging/vcpkg		packaging/vcpkg
src		src
test_package		test_package
tests		tests
.clang-format		.clang-format
.clang-format-ignore		.clang-format-ignore
.clang-tidy		.clang-tidy
.gitattributes		.gitattributes
.gitignore		.gitignore
CHANGELOG.md		CHANGELOG.md
CMakeLists.txt		CMakeLists.txt
CMakePresets.json		CMakePresets.json
CONTRIBUTING.md		CONTRIBUTING.md
LICENSE		LICENSE
README.md		README.md
SECURITY.md		SECURITY.md
conanfile.py		conanfile.py
openapitools.json		openapitools.json

Navigation Menu

Repository files navigation

XYO Financial SDK for C++

📖 Summary

🏗 Architectural Principles

⚙️ System Requirements

📦 Installation & Integration

Option 1: Conan 2 (Recommended)

Option 2: vcpkg

Option 3: CMake `find_package` (Installed Binaries)

Option 4: CMake `FetchContent` (Direct from Source)

🚀 Quickstart Guide

📚 Comprehensive Usage Workflows

1. Single Transaction Enrichment (`enrichTransaction`)

Response Model Fields:

2. Bulk Transaction Submission (`enrichTransactions`)

3. Bulk Job Status Polling (`getEnrichmentStatus`)

4. Direct Bulk Results Download & Decompression (`downloadEnrichmentCollection`)

🚀 Framework & Architecture Integration

1. Modern C++17 Microservice Integration (Crow / Drogon)

Crow Microservice Recipe

Drogon Asynchronous Controller Recipe

2. High-Frequency Trading & Low-Latency Banking Ledgers

🛡 Structured Error Handling (`xyo::Error`)

HTTP Status Code Reference

⚙️ Advanced Configuration Reference

🔒 Security & Compliance

🧪 Build from Source & Run Tests

📞 Support

📄 License

About

Releases

Packages

Contributors

Languages

Latest commit

History

Folders and files

Repository files navigation

XYO Financial SDK for C++

📖 Summary

🏗 Architectural Principles

⚙️ System Requirements

📦 Installation & Integration

Option 1: Conan 2 (Recommended)

Option 2: vcpkg

Option 3: CMake find_package (Installed Binaries)

Option 4: CMake FetchContent (Direct from Source)

🚀 Quickstart Guide

📚 Comprehensive Usage Workflows

1. Single Transaction Enrichment (enrichTransaction)

Response Model Fields:

2. Bulk Transaction Submission (enrichTransactions)

3. Bulk Job Status Polling (getEnrichmentStatus)

4. Direct Bulk Results Download & Decompression (downloadEnrichmentCollection)

🚀 Framework & Architecture Integration

1. Modern C++17 Microservice Integration (Crow / Drogon)

Crow Microservice Recipe

Drogon Asynchronous Controller Recipe

2. High-Frequency Trading & Low-Latency Banking Ledgers

🛡 Structured Error Handling (xyo::Error)

HTTP Status Code Reference

⚙️ Advanced Configuration Reference

🔒 Security & Compliance

🧪 Build from Source & Run Tests

📞 Support

📄 License

About

Resources

Contributing

Security policy

Stars

Watchers

Forks

Releases

Packages

Contributors

Languages

Option 3: CMake `find_package` (Installed Binaries)

Option 4: CMake `FetchContent` (Direct from Source)

1. Single Transaction Enrichment (`enrichTransaction`)

2. Bulk Transaction Submission (`enrichTransactions`)

3. Bulk Job Status Polling (`getEnrichmentStatus`)

4. Direct Bulk Results Download & Decompression (`downloadEnrichmentCollection`)

🛡 Structured Error Handling (`xyo::Error`)
