XYO Financial SDK for Java

The official Java SDK for XYO Financial.
Seamlessly enrich raw financial transactions into clean merchant profiles, intelligent business categorizations, high-res logos, and geolocated address metadata using AI-powered enrichment pipelines.

📖 Summary

The XYO Financial Java SDK delivers a high-performance, strictly typed, thread-safe client library for integrating XYO's transaction enrichment engine into enterprise Java ecosystems. Engineered for Tier-1 financial institutions, neobanks, payment processors, and fintech platforms, this SDK transforms raw, cryptic payment counterparty strings into structured, categorized, and geocoded merchant intelligence.

Maintained by Syniol Limited as the official Java distribution for XYO.Financial, the SDK supports both low-latency synchronous transaction processing paths and high-throughput asynchronous bulk batches.

🏗 Architectural Principles

Modern Java 17+ Baseline: Leverages modern Java language features, immutable record-style builders, JSpecify nullability annotations (@Nullable), and native java.net.http.HttpClient transport.
Thread Safety & Immutability: All client and model instances are defensive-copied and thread-safe. A single XyoClient instance can be safely injected across multiple concurrent application threads.
Resilience & Bounded Latency: Granular connection timeout, request timeout, and maximum response payload bounds prevent runaway latency and memory exhaustion in mission-critical payment pipelines.
RFC 7807 Problem Details Compliance: Rich, structured error handling categorizes operational errors (HTTP, TRANSPORT, VALIDATION, PARSING) and surfaces RFC 7807 compliant problem details for automated Dead-Letter Queue (DLQ) routing and remediation.
Security & Zero PII Footprint: Enforces HTTPS encryption by default (preventing accidental insecure downgrade attacks). Requires only counterparty description and ISO country code—never PAN, CVV, or regulated account credentials.

⚙️ System Requirements

JDK: Java 17 LTS or newer (tested on Java 17, 21, and 22).
Build System: Maven 3.8+ or Gradle 7.0+.
Credentials: A valid API Key from the XYO Dashboard.

📦 Installation

The SDK is published to Maven Central. Add the dependency to your build configuration:

Maven (`pom.xml`)

<dependency>
    <groupId>io.github.xyo-financial</groupId>
    <artifactId>xyo-sdk</artifactId>
    <version>2.1.0</version>
</dependency>

Gradle (`build.gradle` - Groovy DSL)

repositories {
    mavenCentral()
}

dependencies {
    implementation 'io.github.xyo-financial:xyo-sdk:2.1.0'
}

Gradle (`build.gradle.kts` - Kotlin DSL)

repositories {
    mavenCentral()
}

dependencies {
    implementation("io.github.xyo-financial:xyo-sdk:2.1.0")
}

🚀 Quickstart Guide

1. Client Configuration & Initialization

Initialize XyoClient using the immutable ClientConfig.Builder. In enterprise environments, manage XyoClient as a singleton managed bean (e.g., via Spring @Bean, Quarkus @ApplicationScoped, or Guice @Provides).

package com.example.billing;

import financial.xyo.ClientConfig;
import financial.xyo.XyoClient;
import java.net.http.HttpClient;
import java.time.Duration;

public class XyoClientProvider {

    public static XyoClient createClient() {
        ClientConfig config = new ClientConfig.Builder(System.getenv("XYO_API_KEY"))
                .apiBaseUrl(ClientConfig.DEFAULT_API_BASE_URL) // https://api.xyo.financial
                .connectTimeoutMs(5000)                        // 5s connection timeout
                .requestTimeoutMs(15000)                       // 15s request read timeout
                .maxResponseBytes(1024 * 1024)                 // 1MB response size guard
                .allowInsecureHttp(false)                      // Strict TLS enforcement
                .httpClient(HttpClient.newBuilder()
                        .connectTimeout(Duration.ofSeconds(5))
                        .followRedirects(HttpClient.Redirect.NORMAL)
                        .build())
                .build();

        return new XyoClient(config);
    }
}

2. Enrich Single Payment Transaction (`enrichTransaction`)

Execute real-time, synchronous transaction enrichment on payment authorization hooks or statement view generation:

package com.example.billing;

import financial.xyo.EnrichmentRequest;
import financial.xyo.EnrichmentResponse;
import financial.xyo.XyoClient;
import financial.xyo.XyoException;

public class TransactionEnrichmentService {

    private final XyoClient xyoClient;

    public TransactionEnrichmentService(XyoClient xyoClient) {
        this.xyoClient = xyoClient;
    }

    public void processPayment(String rawDescription, String isoCountryCode) {
        try {
            EnrichmentRequest request = new EnrichmentRequest(rawDescription, isoCountryCode);
            // Alternatively using the Builder:
            // EnrichmentRequest request = new EnrichmentRequest.Builder()
            //         .content(rawDescription)
            //         .countryCode(isoCountryCode)
            //         .build();

            EnrichmentResponse response = xyoClient.enrichTransaction(request);

            System.out.println("Merchant Identified: " + response.getMerchant());
            System.out.println("Clean Description:   " + response.getDescription());
            System.out.println("Categories:          " + String.join(", ", response.getCategories()));
            System.out.println("Logo URL:            " + response.getLogo());
            System.out.println("Location:            " + (response.getLocation() != null ? response.getLocation() : "N/A"));
            System.out.println("Address:             " + (response.getAddress() != null ? response.getAddress() : "N/A"));

        } catch (XyoException ex) {
            System.err.printf("Enrichment failed [%s]: %s (HTTP %d)%n",
                    ex.getCategory(), ex.getMessage(), ex.getHttpStatusCode());
            throw ex;
        }
    }
}

3. Bulk Transaction Enrichment (`enrichTransactionCollection`)

For high-volume ETL pipelines, nightly reconciliations, or large statement migrations, submit batches asynchronously:

package com.example.billing;

import financial.xyo.EnrichTransactionCollectionResponse;
import financial.xyo.EnrichmentRequest;
import financial.xyo.XyoClient;
import java.util.List;

public class BatchEnrichmentService {

    private final XyoClient xyoClient;

    public BatchEnrichmentService(XyoClient xyoClient) {
        this.xyoClient = xyoClient;
    }

    public EnrichTransactionCollectionResponse submitBatch(List<EnrichmentRequest> transactions) {
        // Submit collection for asynchronous processing
        // Optional x-api-user header can also be passed via overload: enrichTransactionCollection(transactions, "tenant-user-123")
        EnrichTransactionCollectionResponse response = xyoClient.enrichTransactionCollection(transactions);

        System.out.println("Batch Queued Successfully!");
        System.out.println("Batch ID:    " + response.getId());
        System.out.println("Status Link: " + response.getLink());

        return response;
    }
}

4. Check Collection Status (`enrichTransactionCollectionStatus`)

Poll or track the progress of an asynchronous bulk enrichment task:

package com.example.billing;

import financial.xyo.EnrichmentCollectionStatus;
import financial.xyo.XyoClient;

public class BatchStatusMonitor {

    private final XyoClient xyoClient;

    public BatchStatusMonitor(XyoClient xyoClient) {
        this.xyoClient = xyoClient;
    }

    public EnrichmentCollectionStatus checkBatchStatus(String batchId) throws InterruptedException {
        EnrichmentCollectionStatus status = xyoClient.enrichTransactionCollectionStatus(batchId);

        while (status == EnrichmentCollectionStatus.PENDING) {
            System.out.println("Batch " + batchId + " is still processing. Waiting 3 seconds...");
            Thread.sleep(3000);
            status = xyoClient.enrichTransactionCollectionStatus(batchId);
        }

        switch (status) {
            case READY -> System.out.println("Batch " + batchId + " is READY for result retrieval.");
            case FAILED -> System.err.println("Batch " + batchId + " processing FAILED.");
            default -> throw new IllegalStateException("Unexpected status: " + status);
        }

        return status;
    }
}

5. Download Bulk Enrichment Results (`downloadEnrichmentCollection`)

Once a bulk enrichment job has reached READY status, download and decompress the .tar.gz archive of enriched results:

package com.example.billing;

import financial.xyo.EnrichmentCollectionStatus;
import financial.xyo.EnrichmentResponse;
import financial.xyo.XyoClient;
import financial.xyo.XyoException;
import java.util.List;

public class BatchResultDownloader {

    private final XyoClient xyoClient;

    public BatchResultDownloader(XyoClient xyoClient) {
        this.xyoClient = xyoClient;
    }

    public List<EnrichmentResponse> downloadResults(String downloadUrl) {
        try {
            // Downloads .tar.gz archive, decompresses gzip stream, and parses JSON records
            List<EnrichmentResponse> results = xyoClient.downloadEnrichmentCollection(downloadUrl);

            System.out.printf("Downloaded %d enriched transaction records.%n", results.size());
            for (EnrichmentResponse item : results) {
                System.out.printf("  - %s: %s [%s]%n",
                        item.getMerchant(),
                        item.getDescription(),
                        String.join(", ", item.getCategories()));
            }

            return results;
        } catch (XyoException ex) {
            System.err.printf("Failed to download results [%s]: %s (HTTP %d)%n",
                    ex.getCategory(), ex.getMessage(), ex.getHttpStatusCode());
            throw ex;
        }
    }
}

🚀 Framework & Architecture Integration

The XyoClient is engineered for modern enterprise microservices, cloud-native deployments, and serverless runtimes. Designed to be strictly thread-safe and immutable, a single XyoClient instance should be registered as a singleton bean in your dependency injection container and shared across concurrent execution threads.

Spring Boot 3.x / Jakarta EE

Define a @Configuration class to expose XyoClient as a Spring-managed bean. Specifying @Bean(destroyMethod = "close") ensures proper lifecycle teardown when the ApplicationContext is closed:

package com.example.config;

import financial.xyo.ClientConfig;
import financial.xyo.XyoClient;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

import java.time.Duration;

@Configuration
public class XyoConfig {

    @Bean(destroyMethod = "close")
    public XyoClient xyoClient(@Value("${xyo.api.key}") String apiKey) {
        ClientConfig config = new ClientConfig.Builder(apiKey)
                .connectTimeoutMs(2000)
                .requestTimeoutMs(2000)
                .build();

        return new XyoClient(config);
    }
}

Inject and consume anywhere across your Spring services or controllers:

package com.example.billing;

import financial.xyo.EnrichmentRequest;
import financial.xyo.EnrichmentResponse;
import financial.xyo.XyoClient;
import org.springframework.stereotype.Service;

@Service
public class PaymentProcessingService {

    private final XyoClient xyoClient;

    public PaymentProcessingService(XyoClient xyoClient) {
        this.xyoClient = xyoClient;
    }

    public EnrichmentResponse process(String rawMerchant, String countryCode) {
        return xyoClient.enrichTransaction(new EnrichmentRequest(rawMerchant, countryCode));
    }
}

Quarkus & Jakarta CDI

For Quarkus applications, declare XyoClient as an @ApplicationScoped CDI producer:

package com.example.config;

import financial.xyo.ClientConfig;
import financial.xyo.XyoClient;
import jakarta.enterprise.context.ApplicationScoped;
import jakarta.enterprise.inject.Disposes;
import jakarta.enterprise.inject.Produces;
import org.eclipse.microprofile.config.inject.ConfigProperty;

@ApplicationScoped
public class XyoClientProducer {

    @Produces
    @ApplicationScoped
    public XyoClient produceXyoClient(@ConfigProperty(name = "xyo.api.key") String apiKey) {
        ClientConfig config = new ClientConfig.Builder(apiKey)
                .connectTimeoutMs(2000)
                .requestTimeoutMs(2000)
                .build();

        return new XyoClient(config);
    }

    public void close(@Disposes XyoClient client) {
        client.close();
    }
}

Micronaut Framework

For Micronaut microservices, register a singleton factory bean:

package com.example.config;

import financial.xyo.ClientConfig;
import financial.xyo.XyoClient;
import io.micronaut.context.annotation.Factory;
import io.micronaut.context.annotation.Value;
import jakarta.inject.Singleton;

@Factory
public class XyoClientFactory {

    @Singleton
    public XyoClient xyoClient(@Value("${xyo.api.key}") String apiKey) {
        ClientConfig config = new ClientConfig.Builder(apiKey)
                .connectTimeoutMs(2000)
                .requestTimeoutMs(2000)
                .build();

        return new XyoClient(config);
    }
}

GraalVM Native Image & AOT Compatibility

The XYO Java SDK is designed for Ahead-of-Time (AOT) compilation with GraalVM Native Image, Quarkus Native, and Spring Boot Native AOT:

⚡ Sub-8ms Cold Starts: Instant startup time for serverless functions (AWS Lambda, Google Cloud Run, Azure Functions) and scale-to-zero workloads.
🛡️ Zero Runtime Reflection Proxies: Built on JDK 17+ native java.net.http.HttpClient transport and Jackson serialization with no dynamic bytecode generation or CGLIB proxies.
💾 Ultra-Low Memory (<25MB RSS): Minimal resident memory consumption on containerized platforms (Kubernetes, Red Hat OpenShift, AWS ECS/Fargate), maximizing vertical pod density.
🔒 Native TLS Transport: Built-in TLS 1.3 / 1.2 negotiation without requiring external C/JNI crypto binaries.

🛡️ Robust RFC 7807 Error Handling

The XYO API adheres to the RFC 7807 (Problem Details for HTTP APIs) specification. Non-2xx HTTP responses return structured problem detail documents (application/problem+json or application/json).

The Java SDK captures both low-level transport/OpenAPI exceptions (ApiException) and normalizes all failures into strongly typed XyoException runtime exceptions with discrete ErrorCategory classifications.

Error Taxonomy

Category (`ErrorCategory`)	Description	Typical Cause	Enterprise Mitigation
`VALIDATION`	Client-side validation failure	Blank content, invalid country code, null config	Validate upstream transaction attributes before sending.
`HTTP`	Non-2xx response from XYO API	400 Bad Request, 401 Unauthorized, 429 Rate Limit	Parse RFC 7807 JSON body (`ex.getResponseBody()`) for field-level error details.
`TRANSPORT`	Network / I/O transport fault	Connect timeout, TCP reset, DNS resolution failure	Trigger exponential backoff retry with jitter.
`PARSING`	Response deserialization failure	Malformed payload or unparseable schema	Inspect raw payload; alert Syniol API support team.

RFC 7807 Parsing Pattern

package com.example.billing;

import com.fasterxml.jackson.annotation.JsonIgnoreProperties;
import com.fasterxml.jackson.databind.ObjectMapper;
import financial.xyo.client.ApiException;
import financial.xyo.ErrorCategory;
import financial.xyo.XyoException;

public class EnterpriseErrorHandler {

    private static final ObjectMapper OBJECT_MAPPER = new ObjectMapper();

    /**
     * RFC 7807 Problem Details representation.
     */
    @JsonIgnoreProperties(ignoreUnknown = true)
    public record ProblemDetails(
            String type,
            String title,
            Integer status,
            String detail,
            String instance
    ) {}

    public static void handleException(XyoException ex) {
        if (ex.getCategory() == ErrorCategory.HTTP) {
            int httpStatus = ex.getHttpStatusCode();
            String rawBody = ex.getResponseBody();

            System.err.printf("HTTP Error %d encountered.%n", httpStatus);

            if (rawBody != null && !rawBody.isBlank()) {
                try {
                    ProblemDetails problem = OBJECT_MAPPER.readValue(rawBody, ProblemDetails.class);
                    System.err.printf("RFC 7807 Detail -> Title: '%s', Detail: '%s', Type: '%s'%n",
                            problem.title(), problem.detail(), problem.type());
                } catch (Exception parseEx) {
                    System.err.println("Raw Response Body: " + rawBody);
                }
            }

            switch (httpStatus) {
                case 400 -> System.err.println("Routing to Dead-Letter Queue (DLQ) for manual inspection.");
                case 401, 403 -> System.err.println("CRITICAL: Invalid API Key. Triggering SecOps key rotation alert.");
                case 429 -> System.err.println("Rate limit reached. Applying exponential backoff with jitter.");
                case 500, 502, 503, 504 -> System.err.println("Upstream service degradation. Engaging circuit-breaker.");
                default -> System.err.println("Unhandled HTTP status code.");
            }
        } else if (ex.getCategory() == ErrorCategory.TRANSPORT) {
            System.err.println("Transport failure: " + ex.getMessage() + " (Cause: " + ex.getCause() + ")");
        } else if (ex.getCategory() == ErrorCategory.VALIDATION) {
            System.err.println("Client validation failed: " + ex.getMessage());
        }
    }
}

🔒 Security & Operational Best Practices

Credential Management: Store your API key securely using a Secret Manager (AWS Secrets Manager, HashiCorp Vault, Azure Key Vault, or Kubernetes Secrets). Do not hardcode API keys in source control.
Connection Pooling: When passing a custom HttpClient, configure appropriate connection pool sizing and HTTP/2 multiplexing for optimal throughput.
Timeouts: Always configure explicit connect and request timeouts. The default SDK timeout is 5 seconds for connection and 30 seconds for request completion.
Data Minimization: Submit only transaction descriptions (e.g., "TFL TRAVEL CHARGE") and ISO country codes (e.g., "GB"). Never transmit cardholder names, PANs, CVVs, or bank account credentials.

🛠️ Building and Testing from Source

# Clone the repository
git clone https://github.com/xyo-financial/sdk-java.git
cd sdk-java

# Compile and execute the full test suite (31 unit & integration boundary tests)
mvn clean test

# Install to local Maven repository cache
mvn clean install

📄 License

This project is licensed under the Apache License, Version 2.0 - see the LICENSE file for details.

Name		Name	Last commit message	Last commit date
.github/workflows		.github/workflows
docs		docs
example		example
openapi		openapi
xyo-sdk		xyo-sdk
.editorconfig		.editorconfig
.gitattributes		.gitattributes
.gitignore		.gitignore
.prettierignore		.prettierignore
CHANGELOG.md		CHANGELOG.md
CONTRIBUTING.md		CONTRIBUTING.md
LICENSE		LICENSE
README.md		README.md
SECURITY.md		SECURITY.md
openapitools.json		openapitools.json
pom.xml		pom.xml

Navigation Menu

Repository files navigation

XYO Financial SDK for Java

📖 Summary

🏗 Architectural Principles

⚙️ System Requirements

📦 Installation

Maven (`pom.xml`)

Gradle (`build.gradle` - Groovy DSL)

Gradle (`build.gradle.kts` - Kotlin DSL)

🚀 Quickstart Guide

1. Client Configuration & Initialization

2. Enrich Single Payment Transaction (`enrichTransaction`)

3. Bulk Transaction Enrichment (`enrichTransactionCollection`)

4. Check Collection Status (`enrichTransactionCollectionStatus`)

5. Download Bulk Enrichment Results (`downloadEnrichmentCollection`)

🚀 Framework & Architecture Integration

Spring Boot 3.x / Jakarta EE

Quarkus & Jakarta CDI

Micronaut Framework

GraalVM Native Image & AOT Compatibility

🛡️ Robust RFC 7807 Error Handling

Error Taxonomy

RFC 7807 Parsing Pattern

🔒 Security & Operational Best Practices

🛠️ Building and Testing from Source

📄 License

About

Releases

Packages

Contributors

Languages

Latest commit

History

Folders and files

Repository files navigation

XYO Financial SDK for Java

📖 Summary

🏗 Architectural Principles

⚙️ System Requirements

📦 Installation

Maven (pom.xml)

Gradle (build.gradle - Groovy DSL)

Gradle (build.gradle.kts - Kotlin DSL)

🚀 Quickstart Guide

1. Client Configuration & Initialization

2. Enrich Single Payment Transaction (enrichTransaction)

3. Bulk Transaction Enrichment (enrichTransactionCollection)

4. Check Collection Status (enrichTransactionCollectionStatus)

5. Download Bulk Enrichment Results (downloadEnrichmentCollection)

🚀 Framework & Architecture Integration

Spring Boot 3.x / Jakarta EE

Quarkus & Jakarta CDI

Micronaut Framework

GraalVM Native Image & AOT Compatibility

🛡️ Robust RFC 7807 Error Handling

Error Taxonomy

RFC 7807 Parsing Pattern

🔒 Security & Operational Best Practices

🛠️ Building and Testing from Source

📄 License

About

Resources

Contributing

Security policy

Stars

Watchers

Forks

Releases

Packages

Contributors

Languages

Maven (`pom.xml`)

Gradle (`build.gradle` - Groovy DSL)

Gradle (`build.gradle.kts` - Kotlin DSL)

2. Enrich Single Payment Transaction (`enrichTransaction`)

3. Bulk Transaction Enrichment (`enrichTransactionCollection`)

4. Check Collection Status (`enrichTransactionCollectionStatus`)

5. Download Bulk Enrichment Results (`downloadEnrichmentCollection`)
